Gateway Authentication

Every gateway request is authenticated before any tool is executed. almyty enforces a default-deny policy — gateways with no auth configured reject all requests.

Authentication Methods

Method	Header / Parameter	Use Case
None	—	Public/development gateways (must be explicitly configured)
API Key	`X-API-Key` header or `api_key` query param	Machine-to-machine
Bearer Token	`Authorization: Bearer <token>`	Programmatic access
Basic Auth	`Authorization: Basic <base64>`	Legacy integrations
JWT	`Authorization: Bearer <jwt>`	Signed, self-contained tokens
OAuth 2.1	`Authorization: Bearer <oauth-token>`	Full authorization code flow with PKCE

How Enforcement Works

Every request to /mcp/*, /utcp/*, or /a2a/* passes through the same enforcement pipeline:

Resolve the organization and gateway from the URL
Load all active auth configs for that gateway
If no auth configs exist → reject (401)
Try each required auth method in order — first success wins
If all fail → reject with the last error (401 or 403)
If valid → execute the request

Discovery endpoints (.well-known/*, agent cards) are always public.

Configuring Authentication

Via the UI

Open the gateway detail page
Click the Authentication tab
Click Add Auth Method
Select the type and configure

Via the API

curl -X POST https://api.almyty.com/gateways/{id}/auth \
  -H "Authorization: Bearer $TOKEN" \
  -H "Content-Type: application/json" \
  -d '{
    "type": "api_key",
    "isRequired": true,
    "configuration": {
      "keyHeader": "X-API-Key"
    }
  }'

API Key Authentication

API keys are stored as SHA-256 hashes in the database. The raw key is only shown once at creation time.

Generate a Key

curl -X POST https://api.almyty.com/gateways/{id}/auth/api-keys \
  -H "Authorization: Bearer $TOKEN" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "Production Key",
    "scopes": ["tools:read", "tools:execute"],
    "expiresAt": "2027-01-01T00:00:00Z"
  }'

Response (key shown once):

{
  "id": "key-uuid",
  "name": "Production Key",
  "key": "almyty_gw_abc123...",
  "scopes": ["tools:read", "tools:execute"],
  "expiresAt": "2027-01-01T00:00:00Z"
}

Using the Key

# Via custom header (default: X-API-Key)
curl https://api.almyty.com/mcp/acme/my-tools \
  -H "X-API-Key: almyty_gw_abc123..."

# Via query parameter (default: api_key)
curl "https://api.almyty.com/mcp/acme/my-tools?api_key=almyty_gw_abc123..."

Validation

Key is hashed with SHA-256 and looked up in the database
Checks: key exists, is active, not expired
Supports gateway-specific keys and org-wide keys
Optional: min/max key length, regex format validation
lastUsedAt is updated on each successful request

Manage Keys

# List keys
curl https://api.almyty.com/gateways/{id}/auth/api-keys \
  -H "Authorization: Bearer $TOKEN"

# Revoke a key
curl -X DELETE https://api.almyty.com/gateways/{id}/auth/api-keys/{keyId} \
  -H "Authorization: Bearer $TOKEN"

Bearer Token Authentication

Bearer tokens use the same infrastructure as API keys — they're hashed with SHA-256 and looked up in the ApiKey table.

curl https://api.almyty.com/mcp/acme/my-tools \
  -H "Authorization: Bearer almyty_gw_abc123..."

Basic Auth

Decodes the Authorization: Basic header, looks up the user by email, and verifies the password with bcrypt.

curl https://api.almyty.com/mcp/acme/my-tools \
  -H "Authorization: Basic $(echo -n 'user@example.com:password' | base64)"

The authenticated user's organization membership and roles are included in the auth result.

JWT Authentication

Verifies JWT signature using the secret configured on the auth method (or falls back to the server's JWT_SECRET).

curl https://api.almyty.com/mcp/acme/my-tools \
  -H "Authorization: Bearer eyJhbGciOiJIUzI1NiIs..."

The JWT payload must contain sub or userId. Scopes are read from payload.scopes (array) or payload.scope (space-separated string).

Configure the secret when adding JWT auth to a gateway:

curl -X POST https://api.almyty.com/gateways/{id}/auth \
  -H "Authorization: Bearer $TOKEN" \
  -H "Content-Type: application/json" \
  -d '{
    "type": "jwt",
    "isRequired": true,
    "configuration": {
      "secret": "your-jwt-signing-secret"
    }
  }'

OAuth 2.1 (MCP OAuth)

almyty implements a full OAuth 2.1 authorization server per the MCP specification (opens in a new tab), supporting:

Authorization Code flow with PKCE (S256 required)
Dynamic Client Registration (RFC 7591)
Token Revocation (RFC 7009)
Authorization Server Metadata (RFC 8414)
Protected Resource Metadata (RFC 9728)

Discovery

Every MCP gateway with OAuth enabled exposes metadata endpoints:

# Authorization server metadata
curl https://api.almyty.com/mcp/acme/my-tools/.well-known/oauth-authorization-server

# Protected resource metadata
curl https://api.almyty.com/mcp/acme/my-tools/.well-known/oauth-protected-resource

Client Registration

Clients register dynamically before starting the OAuth flow:

curl -X POST https://api.almyty.com/mcp/acme/my-tools/register \
  -H "Content-Type: application/json" \
  -d '{
    "client_name": "My MCP Client",
    "redirect_uris": ["http://localhost:3000/callback"],
    "grant_types": ["authorization_code", "refresh_token"],
    "response_types": ["code"],
    "token_endpoint_auth_method": "none"
  }'

Response:

{
  "client_id": "mcp_client_abc123...",
  "client_name": "My MCP Client",
  "redirect_uris": ["http://localhost:3000/callback"],
  "grant_types": ["authorization_code", "refresh_token"],
  "response_types": ["code"],
  "token_endpoint_auth_method": "none",
  "client_id_issued_at": 1711234567
}

Redirect URIs must use HTTPS, except localhost and 127.0.0.1 for development.

Authorization Code Flow

Step 1 — Redirect the user to the authorize endpoint:

GET https://api.almyty.com/mcp/acme/my-tools/authorize
  ?response_type=code
  &client_id=mcp_client_abc123...
  &redirect_uri=http://localhost:3000/callback
  &code_challenge=E9Melhoa2OwvFrEMTJguCHaoeK1t8URWbuGJSstw-cM
  &code_challenge_method=S256
  &scope=tools:read tools:execute
  &state=random-state-value

code_challenge_method=S256 is mandatory (OAuth 2.1 requires PKCE)
If the user is not logged in, they're redirected to the login page first
After authentication, an authorization code is generated (10-minute lifetime)

Step 2 — Exchange the code for tokens:

curl -X POST https://api.almyty.com/mcp/acme/my-tools/token \
  -H "Content-Type: application/x-www-form-urlencoded" \
  -d "grant_type=authorization_code\
  &code=auth_code_here\
  &redirect_uri=http://localhost:3000/callback\
  &client_id=mcp_client_abc123...\
  &code_verifier=dBjftJeZ4CVP-mB92K27uhbUJU1p1r_wW1gFWFOEjXk"

Response:

{
  "access_token": "almyty_at_...",
  "token_type": "bearer",
  "expires_in": 3600,
  "refresh_token": "almyty_rt_...",
  "scope": "tools:read tools:execute"
}

Access tokens expire in 1 hour
Refresh tokens expire in 30 days
Both are stored as SHA-256 hashes (never plaintext)

Step 3 — Use the access token:

curl -X POST https://api.almyty.com/mcp/acme/my-tools \
  -H "Authorization: Bearer almyty_at_..." \
  -H "Content-Type: application/json" \
  -d '{
    "jsonrpc": "2.0",
    "method": "tools/list",
    "id": 1
  }'

Refreshing Tokens

curl -X POST https://api.almyty.com/mcp/acme/my-tools/token \
  -H "Content-Type: application/x-www-form-urlencoded" \
  -d "grant_type=refresh_token\
  &refresh_token=almyty_rt_...\
  &client_id=mcp_client_abc123..."

Refresh tokens are rotated — the old refresh token is revoked when a new one is issued.

Revoking Tokens

curl -X POST https://api.almyty.com/mcp/acme/my-tools/revoke \
  -H "Content-Type: application/x-www-form-urlencoded" \
  -d "token=almyty_at_...&client_id=mcp_client_abc123..."

Revoking a refresh token also revokes all associated access tokens. Per RFC 7009, this endpoint always returns 200.

Security Properties

PKCE mandatory — Only S256, no plain
One-time codes — Authorization codes are marked used after exchange
Replay detection — Reused codes trigger a warning
Token rotation — Old refresh tokens are revoked on refresh
Hash-only storage — Tokens stored as SHA-256 hashes, never plaintext

IP Restrictions

Any auth method can include IP restrictions:

{
  "validationRules": {
    "allowedIpRanges": ["10.0.0.0/8", "192.168.1.100"]
  }
}

Supports CIDR notation and individual IPs. Requests from non-whitelisted IPs are rejected.

Required Headers

Force clients to include specific headers:

{
  "validationRules": {
    "requiredHeaders": ["X-Request-Id", "X-Client-Version"]
  }
}

Multiple Auth Methods

A gateway can have multiple auth methods. Each method is either required or optional:

Required methods are tried in order — the first one that matches wins
Optional methods provide fallback — if all are optional and none match, the request is rejected
You can combine methods for gradual migration (e.g., add OAuth while keeping API keys)

Key Scopes

Scope	Description
`tools:read`	List and view tool definitions
`tools:execute`	Execute/invoke tools
`gateway:read`	View gateway configuration

Error Responses

On authentication failure, gateways return:

{
  "error": "Unauthorized",
  "message": "Invalid or expired API key",
  "statusCode": 401
}

MCP endpoints include a WWW-Authenticate header pointing to the OAuth metadata URL, per the MCP spec:

WWW-Authenticate: Bearer resource_metadata="https://api.almyty.com/mcp/acme/my-tools/.well-known/oauth-protected-resource"
