LLM Tools

LLM tools use a language model to generate output based on a prompt template. Instead of calling an endpoint or running code, they send a prompt to a configured LLM provider and return the model’s response — either as raw text or as validated JSON.

In the UI

Navigate to Tools and click Create Tool
Select LLM as the execution method
Fill in a name and description
Choose an LLM provider and model from your configured providers (set these up under AI Models first)
Write a system prompt with standing instructions for the model
Write a user prompt template using {{parameters.*}} expressions for dynamic values
Define input parameters referenced in the templates
Choose the output mode:
- Text — returns the raw model response as a string
- JSON — instructs the model to return structured JSON, optionally validated against a schema you provide
Adjust temperature and max tokens if needed
Click Create

Output modes

Text mode returns the raw LLM response:


{
  "result": "Here are the key points:\n1. First point\n2. Second point"
}

JSON mode parses the response and optionally validates it against an outputSchema you define. This is useful for classification, entity extraction, and any tool whose consumers expect structured data:


{
  "result": {
    "summary": "Brief overview",
    "keyPoints": ["Point 1", "Point 2"],
    "sentiment": "positive"
  }
}

Via the API


curl -X POST /organizations/{orgId}/tools \
  -H "Authorization: Bearer $TOKEN" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "summarize_text",
    "description": "Summarize a text document into key points",
    "type": "llm",
    "parameters": {
      "type": "object",
      "properties": {
        "text": { "type": "string", "description": "Text to summarize" },
        "maxPoints": { "type": "integer", "description": "Maximum bullet points", "default": 5 }
      },
      "required": ["text"]
    },
    "executionConfig": {
      "providerId": "provider-uuid",
      "model": "gpt-4o",
      "systemPrompt": "You are a concise summarizer. Extract key points from text.",
      "promptTemplate": "Summarize the following text into at most {{parameters.maxPoints}} bullet points:\n\n{{parameters.text}}",
      "temperature": 0.3,
      "maxTokens": 1024,
      "outputMode": "text"
    }
  }'

Configuration reference

Field	Type	Default	Description
`providerId`	string	—	ID of the LLM provider (required)
`model`	string	Provider default	Specific model to use
`systemPrompt`	string	—	System-level instructions
`promptTemplate`	string	—	User prompt with `{{parameters.*}}` expressions
`temperature`	number	`0.7`	Sampling temperature (0 = deterministic, 2 = creative)
`maxTokens`	number	`1024`	Maximum tokens in the response
`outputMode`	string	`text`	`text` for raw string, `json` for parsed JSON
`outputSchema`	JSON Schema	—	When `outputMode` is `json`, validates the response

Prompt templates

Templates support {{parameters.*}} expressions, substituted at execution time:


Translate the following {{parameters.sourceLanguage}} text to {{parameters.targetLanguage}}:

{{parameters.text}}

Output schema (JSON mode)

When using JSON mode, define an output schema to enforce structure:


{
  "outputMode": "json",
  "outputSchema": {
    "type": "object",
    "properties": {
      "summary": { "type": "string" },
      "keyPoints": { "type": "array", "items": { "type": "string" } },
      "sentiment": { "type": "string", "enum": ["positive", "neutral", "negative"] }
    },
    "required": ["summary", "keyPoints"]
  }
}

Supported providers

LLM tools work with any configured LLM provider:

Provider	Models
OpenAI	gpt-4o, gpt-4o-mini, gpt-4-turbo, etc.
Anthropic	claude-sonnet-4-20250514, claude-3.5-haiku, etc.
Custom	Any OpenAI-compatible API endpoint

Configure providers in AI Models before creating LLM tools.

Cost tracking

Each LLM tool execution tracks token usage:


{
  "result": "...",
  "usage": {
    "promptTokens": 120,
    "completionTokens": 85,
    "totalTokens": 205,
    "estimatedCost": "$0.0004"
  }
}

View aggregate usage in the Analytics dashboard.

Common use cases

Tool	System prompt	Output mode
Summarizer	”Extract key points concisely”	text
Classifier	”Classify into categories”	json
Translator	”Translate accurately”	text
Entity extractor	”Extract named entities”	json
Code generator	”Write clean, tested code”	text
Sentiment analyzer	”Analyze sentiment”	json
